Description
Features
● Intelligent tracking algorithms can increase power generation by approximately 2%.
● The transmission components are independently controlled, and each drive is interlocked, allowing for active adjustment of the spindle torque.
● A comprehensive multi-layered protection mechanism ensures reliable and stable equipment operation.
● Innovative external ball bearing design, adaptable to slopes up to 15%.
● Multiple support points result in better structural stability
Control parameters
| control system | microcontroller |
| Tracking accuracy | <2° |
| Anti-shadow tracking | have |
| Night return | have |
| Control Algorithm | SPA astronomical algorithm + tilt sensor closed loop |
| Communication interface | Zigbee/RS485 |
| Adaptable slope | Adaptive 15% |
GQ-T1 System Parameters
| Tracking Form | Single-row independent tracking system |
| Tracker capacity | It can accommodate up to 120 modules. |
| Transmission method | Push rod/spin |
| Support method | Multiple support points, independent control |
| Power supply method | Mains power/string power supply |
| Daily power consumption | 0.026kWh |
| Design wind speed | 47 m/s (ASCE7-10), adjustable according to project site. |
| Operating temperature | -25°C to +60°C, adjustable according to project location. |
| Tracking angle range | ±60° |
